Sony LDM-1750W 17-Inch LCD Monitor

Sony LDM-1750W 17-Inch LCD Monitor

The new LMD-1750W is an elegant 17-inch widescreen LCD monitor designed for demanding broadcast and professional applications. LCD displays are increasingly replacing CRT monitors in the professional arena due to their increased operational flexibility and lower overall ownership cost.

Features:

• New High Definition 1280x768 WXGA LCD Panel
• Enhanced 178 Degree Viewing Angle
• New 10-bit Picture Processing
• Colour Temperature/Gamma Selection
• Multi-Format Signal Support
• Signal Interface Options
• New Picture-In-Picture mode
• Enhanced Audio Level Meter and Video Waveform Monitor
• Selectable Scan Size and Aspect Ratio
• Multiple-Language On-Screen Display
• Video Markers
• Three Colour Tally
• Remote Control Options
• Centralised Monitor-Wall Control
• Stereo Audio Monitoring
• Smart Function Key Lighting
• Protected Controls
• VESA Mounting Standard
• Native HD/SD picture mode

Specifications:

• General
  • Panel Type: a-Si TFT Active Matrix
  • Picture Size: 17-inch(Viewable area, measured diagonally.)
  • Picture Resolution: 1280 x 768 pixels
  • Panel Aspect Ratio: 15:9
  • Panel Bit Depth: 8 bit
  • Input/Output Capability: HD (Digital/Analogue)/SD (Digital/Analogue)
  • Acceptable Computer System: up to WXGA
• Analogue video
  • Composite: BNC x 1 (IN), BNC x 1 (OUT)(Loop-Through, Automatic Termination.)
  • Y/C: 4-pin Mini-DIN x 1 (IN), 4-pin mini-DIN x 1 (OUT)(Loop-Through, Automatic Termination.)
  • Component/RGB: BNC x 3 (IN), BNC x 3 (OUT**)(Loop-Through, Automatic Termination.)
  • HD-15: D-sub 15-pin x 1 (IN)
  • External Sync: BNC x 1 (IN), BNC x 1 (OUT)(Loop-Through, Automatic Termination.)
• Digital interface
  • SD-SDI Input: BKM-220D, BKM-243HS
  • HD-SDI Input: BKM-243HS
  • SDI with Audio Decoding: Yes
  • HDMI: No
  • DVI-D: DVI-D x 1 (IN)
  • Option Boards: 2 slots (BKM-244CC, BKM-243HS, BKM-220D, BKM-229X, BKM-227W)
• Control
  • Parallel:Modular 8-pin x 1
  • Serial: D-sub 9-pin (RS-232C) x 1, RJ-45 modular connector (LAN, 10BASE-T/100BASE-TX) x 1
• Audio
  • Audio Input/Output: Phono Jack x 2 (IN), Phono Jack x 2 (OUT)
  • Built-in Speaker Out: 1.0W + 1.0W Stereo
• Features
  • Signal Processing: 10 bit
  • Colour Matching: ChromaTru
  • Marker: Aspect, Centre, Safety Area
  • Colour Temperature: 9300k, 6500k, user
  • Closed Caption: EIA608 COMPOSITE (standard), EIA708 (BKM-244CC)
  • Aspect Switch: 16:9, 4:3
  • Scan: 0%, 5%
  • Blue Only: Yes
  • H/V Delay: Yes
  • Tally: 3-Colour
  • Smart APA: Yes
  • EIA 19-inch Rack Mounting: MB-530
  • VESA Mounting: 100 x 100 mm, 75 x 75 mm
  • Desk-top Stand: No
  • Li-ion Battery Operation: No
  • DC Operation: 12V
• Supplied Accessories
  • AC power cord
  • Operation manual
