Robe Tarrantula LED Beam/Wash/Effects Fixture

Case can be purchased with a quantity of 4x fixtures.

Building on the success of the LEDWash 1200 and Spiider‘s advanced technology, the all new Tarrantula is the most powerful LED beam/wash/effects fixture on the market. Now equipped with Robe's innovative lens coating technology which brings benefits such as bright and clear lenses, no scratches or marks, higher light output and longer intervals between cleaning.

Features:

• Light source - 1x 60W RGBW and 36x 40W RGBW LED multichips
• Light output - 20.150 lm, 80.200 lx @ 5m
• Zoom range - 4° - 50°
• Effects - pixel control, MCFE™ - Multi-Coloured Flower Effects, virtual colour wheel, tungsten lamp effect, preprogrammed pixel effects, optional beam shaper

Specifications:

• Source:
  • Light source type: 1x 60W RGBW and 36 x 40W RGBW LED multichips
  • LED life expectancy: min. 50.000 hours
  • Typical lumen maintenance: L70/B50 @ 50.000 hours
  • CRI: 76
• Optical system:
  • Robe’s proprietary optical design
  • High - efficiency zoom optical system, ratio 12,5:1
  • Zoom range: 4° - 50°
  • Fixture total lumen output: 20.150 lm
  • Illuminance: 80.200 lx @ 5 m
  • Innovative lens coating technology (Patent pending)
• Dynamic Effects and Features:
  • Colour mixing mode RGBW or CMY
  • Individual control of each RGBW pixel
  • Variable CTO: 2.700K - 8.000K
  • Virtual Colour Wheel: with 66 preset swatches
  • Tungsten lamp effect at whites: 750W, 1.000W, 1.200W, 2.000W, 2.500W lamp emulation for whites from 2.700K to 4.200K (red shift and thermal delay)
  • Colour rainbow effect with variable speed
  • Pre-programmed pixel effects with colour, dimming and strobe chases, waves and pulses at variable speed and direction
  • MCFE™ - Multi-Coloured Flower Effects – creating spectacular multicolour beam effects in the air rotating in both directions at variable speed (patent pending)
  • Strobe effect: variable speed (max. 20 flashes per second)
  • Pre-programmed random strobe & pulse effects
  • High resolution electronic dimming: 0 - 100%
• Control and programming:
  • Setting & Addressing: ROBE Navigation System 2 (RNS2)
  • Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 100 steps), built-in analyser for easy fault finding
  • Protocols: USITT DMX-512, RDM, Art-Net, MA Net, MA Net2, sACN, Kling-Net
  • Wireless CRMX™ technology from Lumen Radio: On request
  • DMX Protocol modes: 6
  • Control channels: 28, 48, 146, 183, 159, 196
  • Pan/Tilt resolution: 16 bit
  • R,G,B,W colour mixing: 8 or 16 bit (internal 18 bit)
  • Zoom: 8 bit
  • Dimmer: 8 or 16 bit (internal 18 bit)
• Movement:
  • Pan movement: 540°
  • Tilt movement: 220°
  • Movement control: Standard and Speed
  • Controllable speed of Pan/Tilt movement
  • EMS™: Electronic Motion Stabilizer system for Pan & Tilt reducing beam deviation caused by truss movement or vibration (Patent pending)
  • Automatic Pan/Tilt position correction
• Thermal specification:
  • Maximum ambient temperature: 45°C (113°F)
  • Maximum surface temperature: 75°C (167°F)
  • Minimum operating temperature: -5°C (23°F)
• Electrical specification and connections:
  • Power supply: Electronic auto-ranging
  • Input voltage range: 100-240 V, 50/60 Hz
  • Power consumption: 1000 W
  • Power in connector: Neutric powerCON TRUE1
  • DMX and RDM data in/out: Locking 3-pin & 5-pin XLR
  • Ethernet port in/out: RJ45
  • Embedded Ethernet switch 10/100 Mbps: 1x in / 1x out
• Approvals:
  • CE Compliant
  • cETLus Compliant (pending)
• Mechanical specification:
  • Height: 587 mm (23.1”)
  • Width: 508 mm (20”)
  • Depth: 257 mm (10.1”)
  • Weight: 21.2 kg (46.7 lbs)
  • Ingress protection rating: IP20
• Rigging:
  • Mounting positions: Horizontally or vertically
  • Universal operating position
  • Mounting points: 2 pairs of ¼-turn locking points
  • 2x Omega adaptors with ¼-turn quick locks
  • Safety cable attachment point
  • Tilt transport lock
• Included items:
  • User Manual
  • Omega Adaptor CL-regular 2 pcs
  • Power cord including powerCON TRUE1 In connector
• Optional accessories:
  • Diffusion filter 2°: 10980417
  • Beam shaper kit: 10980430
  • EggCrate: 10980431
  • Doughty Trigger Clamp: 17030386
  • Safety wire 35 kg: 99011963
  • Single Top Loader Case: 10120234
  • Dual Top Loader Case: 10120235
  • Foam Shell: 20020319
• Legal:
  • Tarrantula™ is a trademark of Robe lighting s. r. o.
  • Tarrantula™ is patented by Robe lighting s. r. o. and is protected by one or more pending or issued patents
