RME M32-DA-PRO-II-D 32-Channel High-End 192 kiloHertz DA Converter with Dante and MADI

RME M32-DA-PRO-II-D 32-Channel High-End 192 kiloHertz DA Converter with Dante and MADI

The RME M-32 DA Pro II-D Dante + MADI 32-Channel D/A Converter is designed to meet the demanding requirements of professional studios, immersive sound installations, live sound systems, and industrial applications that need a reliable solution for reference-class D/A conversion with high-end Dante and MADI network audio processing.

Features:

• 32-channel reference-quality D/A converter, fully symmetrical design
• 32 analog outputs (25-pin D-sub, up to +24 dBu)
• DC-coupled outputs, fully symmetrical signal path, truly balanced
• 2 MADI I/O (via separately available optical SFP and coaxial BNC, up to 128 channels)
• 2 RJ45 ports for Dante network connectivity (up to 64 channels)
• MIDI I/O for legacy MIDI remote
• Wordclock I/O (BNC)
• USB 2.0 for remote control
• SyncCheck and ICC detect when a clock source is not in sync and fall back to other available signals
• MADI Auto-Input provides seamless redundancy
• Integrated matrix for single-channel routing
• 2" display with control knob for full device control
• Large tricolor backlit channel indicators with peak/RMS metering
• Magnetic cover with customizable channel labels
• 15 preset storage, firmware-upgrade persistent
• Lock (optional code) and dark mode
• Remote control via HTTP, JSON, MIDI over MADI, and optional MIDI
• 2 monitored, fully redundant internal PSUs
• Compact 1 RU, 19" enclosure

Specifications:

• Form Factor: Rackmount (Rack-Mountable with Included Hardware)
• Converter Type: D/A Converter
• Number of Channels: 32x D/A (at 192 kHz)
• Maximum Sampling Rate: 192 kHz / 24-Bit
• Number of Microphone Inputs: No
• Analog Audio I/O: 4x DB-25 25-Pin Balanced Line Input
• Digital Audio I/O:
  • 1x BNC Coaxial MADI Input
  • 1x BNC Coaxial MADI Output
  • 1x TOSLINK Optical MADI In & Out
