Blackmagic Design ATEM Camera Control Panel

Blackmagic Design ATEM Camera Control Panel

The ATEM Camera Control Panel provides independent controls for up to 4 URSA Mini, URSA Broadcast, Blackmagic Studio and Micro Studio cameras from a single control panel. You get iris control, shutter speed, white balance, master gain, pedestal, RGB controls for white and black, and more.

Specifications:

Connections

• Ethernet: 2 x 10/100/1000 BaseT with loop output for additional control panels or computers.
• Software Updates: 1 x USB-C for firmware updates.

Product Specifics

• LCD Menu Displays: 4
• Camera Number Display: Green off air, red on air.
• Setup: White and black balance setup.
• 3 Axis Joystick: 4
• Preview Button: 4
• Iris Control: Auto Iris On, Coarse control.
• Panel Active: Protects settings.

Software

• Software Applications: ATEM Software Control Panel.

Operating Systems

• Mac 10.12 Sierra, Mac 10.13 High Sierra or later.
• Windows 8.1 or Windows 10.

Power Requirements

• Input Voltage: 1 x Internal 100 - 240V AC.
• DC Power: 12-30V 3A.
• Redundant Power: Yes
• Power Usage: 30W

Environmental Specifications

• Operating Temperature: 0° to 40° C (32° to 104° F)
• Storage Temperature: -20° to 60° C (-4° to 140° F)
• Relative Humidity: Up to 95%

What's Included

• ATEM Camera Control Panel

Warranty

• 12 Month Limited Manufacturer's Warranty.
